24" Width Continuous Motion Side Sealer Full Auto Impack Pro-Motion 60
$69,500.00
Availability: In stock
SKU
MSW-MP-IMPPMO60
Assembled Size: 148" x 71" x 63"
Working Height: 34"
Cross Sealer Length: 29"
Conveyor Belt Width: 24"
Max Film Width: 39"
Installed Power: 220-240V 3 Phase
The Maripak IMPACK PRO-MOTION Series Fully-Automatic Continuous Motion Side Sealer is a must-have quality built machine designed for fully-automatic side seal applications where high speed and rugged reliability are prime considerations.
Product Description
Lead Time up to 11-15 weeks. Please contact us regarding current lead times.
Maripak's installation service is required for this machine. The additional cost for this service will vary based on the location of installation and other factors.
The Maripak - IMPACK PRO-MOTION Series - Fully-Automatic Continuous Motion Side Sealer is a must-have quality built machine. Maripak’s entry into the standard line of continuous motion side sealers are designed for fully-automatic side seal applications where high speed and rugged reliability are prime considerations.
Built to the same exacting high standards as all of their higher-end wrappers, these versatile units are capable of wrapping many pieces. System estimates are approx 98 feet/minute with 110 cycles/minute depending on size and film type when combined with the proper infeed.
The IMPACK Pro-MOTION 60 is easy to use and rugged enough for constant and consistent operation when extremely fast and accurate product packaging is a must.
See below for specific specification details and information. Configure and build your own machine with options by request.
Maripak’s entry into the standard line of continuous motion side sealers are designed for fully-automatic side seal applications where high speed and rugged reliability are prime considerations in a medium to the large-sized user. Built to the same exacting high standards as all of their higher-end wrappers, these versatile units are capable of wrapping many pieces. System estimates are approx 98 feet/minute with 110 cycles/minute depending on size and film type when combined with the proper infeed.
The IMPACK Pro-MOTION 60 is easy to use and rugged enough for constant and consistent operation on a daily basis while taking up minimal space.
They come standard with premium features not available on most competitive models in this price range including low-mount film cradle, easy operation controls, touchscreen library to easily recall package setups, and automatic dwell time compensator.
The Maripak’s exclusive Hands-on Design make these units the most user-friendly side sealer packaging unit on the market today. World-Wide approved brands for all mechanical and electrical components make the IMPACK Pro-MOTION 60 as popular with maintenance staffs as with operators.
When your application calls for a continuous motion side seal wrapper capable of fully-automatic operation, Maripak’s IMPACK Pro-Motion Series offers the lowest total-cost-in-operation available today with the most advanced and evolved technologies.
ADVANTAGES:
- Very compact and new aesthetic " Pro " design
- Minimized layout requirement due to this new "Pro" design
- Nonstop operation with a continuous motion system
- Continuous side sealer provides unlimited length packaging ability
- Dual-axis servo motor driven cross sealing
- High precision and consistency with cross and side seal
- Very fast and flawless sealing property by the servo drive vertical sealer
- Control of film quantity on all 4 sides of packages for an overall reduction in waste and consumable costs
- Recordable and re-callable package parameter settings
- Easy to integrate with any production line directly
- Packaging runnability with no length limits
- Compact single-chassis, and reduced energy consumption
- Easy to use, compatible with health and safety standards
FEATURES:
- Automatic encoder controlled speed & length detection by sensor synchronization
- User-friendly color touch screen operation control panel
- Ergonomic operators panel with most useful hard buttons
- Easy programmable format changes for different package sizes
- Cross and continuous sealing knives with PID controlled heaters
- Automatic packaging film drive with tension control
- Photocell controlled package distance positioned feeding
- Automatic package length detection option
- Feeding frequency control by sensor detection and PLC control
- Up-to-date safety electric and mechanical measures of CE directives
- Easily transportable on wheels inside a facility
SEALING:
- Film sealing with no distortion with non-stop and tight processing operation
- Up to 15% advantage in film consumption
- Film tension releasing mechanism on the cross-sealing point
- Trim winder is designed to control very thin films without breakage
- Adjustable " Central Sealing " for varied package height applications
- Alternative sealing blade structures for various packaging film materials
- Height adjustable cross sealer (optional motorized)
- Product clearance control under seal bar by an auto sensor
FLEXIBILITY:
- Easily adjustable for varying product sizes and capacity
- Native and various language options and adaptable touch keyboard
- Memory Recipe property for prompt and package dimension adjustments
- Perfect sealing blade design compatible with varying thicknesses
- Warning notifications and messages for potential emergency cases
- "Navigation Control" for actual throughput and estimated packs/time units
OPTIONAL:
- Double seal feature on cross sealer for high film thickness or PE materials
- Control of external infeed conveyor through the operator panel
- Printed film applicability by marker detection sensor and programing
- Center Folder System for single-layer flat film application
- Vertical photocell to detect thin product/packages
- Ability to control additional conveyors by inverters
- Linking Belt **( 3 bar compressed air required )
QUALITY:
- ISO9001 quality standards with the relevant norm's confirmation
- CE certifications comply with the latest CE directives
- World-wide approved brands for all mechanical and electrical components
- 3-year warranty for non-wearable parts against manufacturing defects or faults
- Warranty extendable by 1-year increments for an additional cost
- Wearable parts are not included in warranty terms
- 1 set of wear parts is provided along with the machine
- 5-year spare part availability is provided
TECHNICAL SPECIFICATIONS
- Seal Bar Opening:10" - (250mm)
- Maximum Conv. Speed:98 ft / minute
- (30 mt / minute) - adjustable - Maximum Cycle:110 cycle / packs / minute
- (example: DIN A4 form) - Maximum Roll Diameter:11" - (270mm) - standard
- Working Height (D):34" - (860mm) - Opional: (+50mm)
- Compressed Air Supply:No - None with standard unit
- ** (see options) - Film Types:POF, PP "V" Knife: 7-40 micron / PE,OPP "W" Knife: 40-80 micron
- Color:Customized - Light Gray
RAL7015 + RAL7010 - Working Principle:Servo Driven
- Cross Sealer Length:29" - (730mm)
- Conveyor Belt Width (A):24" - (600mm)
- Maximum Film Width:39" - (1000mm)
- Installed Power:220-240 Volt - 3 Phase
- Consumption (Max / Average):7 kW / 6 kW
- Dimensions (AxBxC):71 x 148 x 63"
- (1800 x 3750 x 1600mm) - Palletized Size (AxBxC) :79 x 156 x 67"
- (2000 x 3950 x 1700mm) - Weight (Net / Gross):2403 lbs / 2756 lbs
- (1090 kg / 1250 kg)
* For DIN A4 form and IMPACK PRO-MOTION Series servo real working speed depends on the product dimensions and film type.
